FO200 Series 2 Channels Fiber Optic Rotary Joint

1310nm/1550nm

SenRing FO200 Fiber Optic rotary joint ,2 channels fiber(support single mode/multi-mode) can transmit date without loss when 360° unrestricted roating.Specially suitable for some applications which requires to keep unrestricted,continuous or intermittent

INSTALLATION RESOURCES 3D MODEL @TECHNICAL INQUIRY

GET A QUOTE

Features: Can transmit 2 channels fiber optic signal when 360° roating;; length:1310nm/850nm;; Low insertion loss , high speed;; Can be combined to transmit power, control signal, micropower signal of computer antomative control ;; Can be combined with the traditional electric slip ring to transmit power and high-speed data;; Non contact, no friction, long working life, >100 million revolutions (20-30 millions revolutions for signal channel model);

Part no. description

fo200 series FO200 Series 2 Channels Fiber Optic Rotary Joint slip ring description

Drawing

Technical Specification of fo200 series slip ring

itemtype	Single mode（SM）	multi mode（MM）
Bandwidth(nm)	±50
Max insertion Loss，23℃(dB)	4	3.5
Insertion loss fluctuation(dB)	≤2	≤1
Return loss(dB)	≥50( without connector)	≥40(PC)
max power(W)	0.5
Max speed(rpm)	400
Working life	> 200 million
Work Temperature(℃)	-20~60
Storage temperature(℃)	-50~85
